Re: My clutch apears bonded together , when I first start it

Thu Aug 15, 2013 7:55 am

Lee, I don't think brake cleaner will hurt anything, as long as it's dedicated strictly to the lining material. I'm just not sure you'll be able to get enough of it in there where it counts.

Re: My clutch apears bonded together , when I first start it

Thu Aug 15, 2013 9:34 am

Gary Dotson wrote:Lee, I don't think brake cleaner will hurt anything, as long as it's dedicated strictly to the lining material. I'm just not sure you'll be able to get enough of it in there where it counts.

I agree with this, both points. Just to add the more-or-less obvious, block the clutch pedal down to do this operation and leave it that way long enough for the remaining cleaner to evaporate.

Re: My clutch apears bonded together , when I first start it

Thu Aug 15, 2013 9:39 am

Jim Becker wrote:
Gary Dotson wrote:Lee, I don't think brake cleaner will hurt anything, as long as it's dedicated strictly to the lining material. I'm just not sure you'll be able to get enough of it in there where it counts.

I agree with this, both points. Just to add the more-or-less obvious, block the clutch pedal down to do this operation and leave it that way long enough for the remaining cleaner to evaporate.


Lee:

To answer your question .. no I haven't used brake cleaner on the clutch, but I haven't had that issue either. However I would defer automatically to both Jim's and Gary's advise on this :D

Re: My clutch apears bonded together , when I first start it

Thu Aug 15, 2013 11:45 am

It may take a couple applications of penetrating oil to the pilot bushing for it to get sufficiently lubricated.

Re: My clutch apears bonded together , when I first start it

Thu Aug 15, 2013 11:53 am

A big thanks, again to all,
After reading Gary's post , the thought of "strapping down " the clutch pedal, in the disengaged position, quickly came to my mind as well, Jim ! In fact I even strapped it down prior to the pilot bearing oiling attempt ! Here is another thought for all to ponder , during the "cold months" , with no thought of driving the Cub, I have even strapped the clutch pedal down for months at a time, When I finally start it again, I first take off the strap, it works just fine, NO BONDING , if that was the pilot bearing issue , the problem would still be their , after the 3 or 4 months , of storage with strap !!
Maybe my 3/8" of free-play , at the disengaged down position , isn't enought ! But that is my limit , with if fully adjusted in that direction, with the "thick" clutch plate materials ( I felt I took out all the "slop" with the linkage , with this "old style" set-up ) !
Again a BIG , thanks to all, including Rudi, with your "long distance" help !
Lee Petrie, Joliet, IL.

Re: My clutch apears bonded together , when I first start it

Sun Aug 18, 2013 8:55 pm

GREAT NEWS from this end , my clutch "bonding issue" is resolved ! It turned out to be a a dry (binding) pilot bushing bearing , and slow in reacting to the spray oil I applied by the straw method ! The morning start, after the oil treatment , and for the last several days , it has been working just fine , NO moving ahead when started in gear ( with the clutch depressed !
A BIG thanks to everyone for their help, I'm including a "before & after" pictures of my nearly completed project '48 Cub , lites , decals, and depth control lever (early style), still need to be attached !
I so happy to be apart of this Cub Group ! Lee Petrie, Joliet, IL




Re: My clutch apears bonded together , when I first start it

Sun Aug 18, 2013 9:50 pm

Lee:

My, my... that does look like a right pretty shiny Cub :big smile: You done did good :D

Re: My clutch apears bonded together , when I first start it

Mon Aug 19, 2013 7:58 am

Hi Rudi,
Thanks for the "thumbs-up" , for the shinny paint job, but to be entirely honest , It wasn't my work, I did some "horse trading" in that project, but it was my efforts entirely on the mechanical part of the restoration ! I even exchanged the #2 exhaust valve, with a new Delco Light Plant Exhaust valve , 1/16" larger in dia., to make-up for bad seat damage, caused by taking on water over a 10 years period !
My question to you is ; Sometime back, one of our members , who was with Jeep assembly in Detroit said how he put on the decals , how can I find that post , hopefully attaching mine , easily and straight appearing ? Lee Petrie, Joliet, IL.

Re: My clutch apears bonded together , when I first start it

Mon Aug 19, 2013 8:10 am

Lee, I put "worked at jeep" in the search and Big Bill and Rick Prentis popped up. Maybe it was one of them.

Re: My clutch apears bonded together , when I first start it

Mon Aug 19, 2013 11:21 am

Thanks Mike,
I did some more research , with those names in mind, it was Rick with a Jan. 2012 post, that was the exact "post", I was looking for ! Thanks for leading me in the correct direction, Lee Petrie, Joliet, IL.

Re: My clutch apears bonded together , when I first start it

Wed Aug 21, 2013 7:41 am

Looks real nice Lee! I see you added a receiver to your fast hitch, makes for a very convenient trailer mover. Glad you got your clutch freed up.

Re: My clutch apears bonded together , when I first start it

Wed Aug 21, 2013 9:32 am

Hi Ray, I'm going to "coin" a new term, "Farm Tractors" are all around, but for those that live in the city , the Cub becomes a "City Tractor" ! Yes, that receiver hitch comes in handy for moving trailers , but when it is removed, I can install my fabricated mounting stand, for the corn cracker , that I take to 3 to 4 farm shows per year , giving the chicken (bird) feed , free to all, in "pocket size", plastic bags ( shown on the far left side of the attached picture) ! Just another side of the Cub World, Lee Petrie, Joliet, IL.
